CA-EPQ0030PR

Product Title

Carbon Audio CA-EPQ0030PR – 5-Band Equalizer with Built-in Epicenter (PRO Series)

Product Overview

If you’re looking to give your car audio system both fine control over tone and a stronger low-end kick, the CA-EPQ0030PR from the PRO series by Carbon Audio is designed for that. With five-band equalization coupled with an epicenter (bass-restoration) circuit, this module is built to deliver clean signal shaping and enhanced low-frequency output — perfect for systems where you want both fidelity and impactful bass.

---

Key Features

5-Band Equalizer + Epicenter Functionality: Tailored for systems where you want user-control over mid/high bands plus a dedicated low-frequency restoration channel.

High Input/Output Headroom: Maximum input up to ~15 V; maximum output peaks around ~13.2 V.

Wide Frequency Response: 10 Hz to 35 kHz (±1 dB) — meaning it covers both deep bass and the full audio spectrum for a clean signal path.

Low Distortion & High Signal Quality: Total harmonic distortion listed at ~0.0025%; signal-to-noise around 133 dB; input balance >62 dB.

Professional Input/Output Impedance: Input impedance ~10 kΩ; output ~150 Ω, making it suitable for integration with high-quality preamp or amplifier fronts.

Compact & Install-Friendly: Weight ~0.65 kg; dimensions around 24 × 5 × 15 cm.
