CA-AD80005PR

Overview

The CA‑AD80005PR is a 5‑channel Class D amplifier from Carbon Audio’s “PRO” or “PR” series. It’s built to power a full system—driving four full‑range speakers plus a subwoofer—using one amplifier unit. According to one listing, it’s identified as “Amplificador Clase D 5 canales Carbon Audio CA‑AD80005PR”.

---

⚙️ Key Specifications & Features

From the listing found:

Channels: 5 (4 channels for speakers + 1 channel likely for sub)

Class: D (efficient for multi‑channel car audio install)

RMS & marketing figures (subject to buyer verification):

4 × 100 W @ 4 Ω for the 4 channels (speaker channels)

4 × 150 W @ 2 Ω for the 4 channels (speaker channels)

Bridged mode: 2 channels bridged into ~320 W each or ~800 W for the fifth channel(?) at 1 Ω. Listing states: “2 × 320 W + 800 × 1” (though this is somewhat ambiguous)

Input sensitivity: ~350 mV according to listing.

Bass boost: adjustable 0‑12 dB (for likely the sub channel)

Dimensions: ~337 × 155 × 50 mm (based on listing)

Fuse rating: 40 A x 3 (for protection)
